    3D Scanning Doppler Wind Speed Lidar PPI RHI DBS LOS Programmed Scan Bankable

    Ask Lasest Price
    Brand Name : MOVELASER
    Model Number : Molas 3D
    Price : Dollar 13W$+ (Price consultation customer service)
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 200 set ,1 month
    Delivery Time : 1-2 months
    • Product Details
    • Company Profile

    3D Scanning Doppler Wind Speed Lidar PPI RHI DBS LOS Programmed Scan Bankable

    3D Scanning Doppler Wind Lidar PPI/RHI/DBS/LOS/programmed scan Bankable


    | Product introduction


    Using Molas 3D can completely avoid the problem of insufficient detection by traditional detection methods, and can provide excellent performance in wind field information in sunny weather. Molas 3D continuously scans the glide path area of the aircraft, measures headwinds and crosswind, calculates the wind shear index, and provides real-time warnings


    | Application scenarios


    Provide wind field information to understand the state of wind in the boundary layer .

    Provides accurate and high spatiotemporal wind profile information within a few kilometers of the near surface, filling the gap in low-altitude observations


    | Product parameters


    Basic parameters
    Line-of-sight detection distance8km (corresponding to 75m distance resolution)
    4km (corresponding to 30m distance resolution)
    Distance resolution30m/45m/60m/75m optional
    Accumulation time0.5s/1s/2s/4s/8s optional
    Radial wind speed measurement range-75~+75 m/s
    Radial wind speed measurement accuracy0.1m/s
    Number of distance layersup to 300
    Horizontal scan range360° × n
    Vertical scan range-10°~190°
    Environmental parameters
    Operating temperature and humidity-25~+50℃ (extendable to -40~+60℃),
    5%~100% RH
    IP protection classHousing IP54, core module IP66
    Anticorrosion gradeC4
    Survival wind speed70m/s (fixed by foot or by wire rope)
    Working altitude≤3500m


    | Product Features


    large range:4/8km typical detection distance
    High precision:Pointing accuracy 0.1°, visual direction wind speed accuracy 0.1m/s
    Rich scanning methods:PPI/RHI/DBS/LOS/ Programmable arbitrary scan method


    | Product Image



    Quality 3D Scanning Doppler Wind Speed Lidar PPI RHI DBS LOS Programmed Scan Bankable for sale
